Application
Suitable for trimming oil seals and PU packings with large-sized outer diameter.
Features
Adopts pressurized trimming to overcome uneasy fixation and deformation for large-sized working pieces.
Use vacuum or pressurizing roller to fix working pieces for trimming, lowest cost of mold, and slightly deformed oil seals can be trimmed.
Equips with two knife sets or three knife sets to trim seals.
| SPECIFICATION |
|
| Power |
2KW |
| Voltage |
According to the customer’s assignment |
| Control System | PLC and Air Pressure System |
| Knife Set |
Two Knife Sets or Three Knife Sets |
| Pressure Wheel | one Sets |
| Trimming Range |
O.D.Ø 100-Ø 350mm |
| Working Capacity |
8-12 PCS/min (Adjust based on the product trimming conditions) |
| Optional Accessory (cost required) | Safety Fence and Safety Optical Curtain |
| Machine Size |
（L）1300×（W）1100×（H）1850mm |
| Measurement Ton |
（L）1400×（W）1200×（H）1950mm |
| Machine Weight |
Net Weight：280kg Gross Weight：380kg |
