Application
Suitable for various oil seals rotation durable life testing.
Features
Rotation at high speed or low speed with multi-speed auto control.
Set multi-test conditions of rotation speed, temperature, rotation period time, and present on man-machine interface touch screen. Test finished stop automatically.
Equip with pressurizing system to test the pressure durable life of oil seals.
Test two kinds of oil seals for one time and print reporters.
| SPECIFICATION |
|
| Power |
9KW |
| Test Shaft | Two Shafts |
| Voltage |
According to the customer’s assignment |
| Principal Shaft R.P.M | Max. 8000 RPM、 speed adjustable |
| Control System | PLC, Air Pressure System and Man-Machine Interface Touch Screen |
| Working Range |
Oil Seal Outer Diameter Ø20-Ø185 mm |
| Test temperature |
Max. 120°C |
| Machine Size |
（L）1350×（W）1250×（H）1850mm |
| Measurement Ton |
（L）1400×（W）1350×（H）1950mm |
| Machine Weight |
Net Weight：1300kg Gross Weight：1450kg |
