Application
Suitable for applying adhesive to oil seals to fix wool felt or non-woven fabric.
Features
Share fixtures with SY-C103 Collet Chuck Type Trimming Machine to cut down the cost of mold economically and efficiently.
Depending on the sample characteristics, either horizontal or vertical coating can be used.
| SPECIFICATION |
|
| Power |
0.5KW |
| Voltage |
Single Phrase 220V 50/60HZ |
| Control System | Air Pressure and PLC |
| Gluing Unit | One set |
| Gluey Material | Silicone and Others |
| Trimming Range |
Oil Seals O.D. Ø10-210mm |
| Working Capacity |
15-25 PCS/min (Adjust based on the product characteristics) |
| Machine Size |
（L）780×（W）620×（H）1500mm |
| Measurement Ton |
（L）880×（W）720×（H）1600mm |
| Machine Weight |
Net Weight：180kg Gross Weight：280kg |
